Heat-Resistant Automotive Wires

Thin-walled automotive wires have significant advantages. Its insulation layer is thin, making the outer diameter of the wire small and its weight light, which is conducive to reducing the load on the car and improving the space utilization rate. It also has excellent flexibility, making it convenient for complex wiring inside the vehicle. Meanwhile, it can withstand temperatures ranging from -40℃ to +105℃ and is resistant to the corrosion of gasoline and diesel, ensuring the stable operation of the automotive electrical system.

2.Implement standards

Enterprise Standard "Wires and Cables for Automobiles"

3. Scope of implementation

The internal connection wires of automobiles have excellent mechanical properties such as high and low temperature resistance and scratch resistance.

4. Technical Parameters

Sectional area	Number of conductor strands	The maximum diameter of a single conductor filament	Maximum outer diameter of the cable	The maximum direct current resistance of the conductor at 20℃
mm2	Root number	mm	mm	Ω/km
0.35	12	0.21	1.4	52.0
0.5	16	0.21	1.6	37.1
0.75	24	0.21	1.9	24.7
1.0	32	0.21	2.1	18.5
1.5	30	0.26	2.4	12.7
2.5	50	0.26	3.0	7.6
4.0	56	0.31	3.7	4.7
6.0	84	0.31	4.3	3.1
