Medium chrome forging Cylpebs

Material:Chrome

Content:10%-28%

Usage:Construction,Machinery,chemical,Petroleum,Grind,Refractory Material,Cement Plant,Mining Mill

Processing Type:Casting

Size:8*10-40*45mm

Color：Black

production Description
Medium chromium grind forging is a metal material with medium chromium content, its properties are between cast steel forging and high chromium forging. chromium forging has good wear resistance, corrosion resistance and toughness, is suitable for some occasions that do not require high material properties. The advantage of chromium forging in is that its manufacturing cost is relatively low, processing difficulty is less, can meet the manufacturing needs of some common mechanical parts and structures. , however, the disadvantage of chromium forging is that its performance is relatively mediocre, not as good as high chromium forging and casting steel forging in some special cases. In addition, the corrosion resistance of chromium forging is not as good as high chromium forging, need to pay attention to the use of some strong acid, strong alkali and other extreme environment.
BASIC INFO

Grinding media information

Model NO.

Medium chromium  grinding forging

Customized

Customized

Hardness

48-55HRC

Heat Treatment

Oil Quenching

Broken Rate

＜0.5%

Moder No.

Zqcr10

Transport Package

Durm or Bag

Specification

High Chrome Grinding Media

Trademark

Chengda

Origin

China

HS Code

7325910000

Production Capacity

60000 Tons

CHEMICAL COMPOSITIONS(%)

Designation

Chemical Compositions(%)

C

Si

Mn

Cr

Mo

P

S

ZDCr26

2.2-3.0

≤1.0

0.3-1.0

24.0-30.0

≤1.0

≤0.10

≤0.06

ZDCr23

2.2-3.0

≤1.0

0.3-1.0

22.0-24.0

≤1.1

≤0.10

≤0.06

ZDCr20

2.2-3.0

≤1.0

0.3-1.0

18.0-22.0

≤1.0

≤0.10

≤0.06

ZDCr17

2.2-3.0

≤1.0

0.3-1.0

16.0-18.0

≤1.0

≤0.10

≤0.06

ZDCr15

2.2-3.0

≤1.0

0.3-1.0

14.0-16.0

≤1.1

≤0.10

≤0.06

ZDCr12

2.2-3.0

≤1.0

0.3-1.0

10.0-14.0

≤1.0

≤0.10

≤0.06

ZDCr8

2.2-3.2

≤1.0

0.3-1.5

7.0-10.0

≤1.0

≤0.10

≤0.06

ZDCr5

2.2-3.2

≤1.0

0.3-1.5

4.0-6.0

≤1.0

≤0.10

≤0.10

ZDCr2

2.2-3.2

≤1.0

0.3-1.5

1.3-3.5

≤1.0

≤0.10

≤0.10

ZDCADI

3.3-3.9

2.4-3.0

2.4-2.9

0.2-0.5

≤0.5

≤0.06

≤0.05

MECHANICAL PROPERTIES AND MICROSTRUCTURE

Designation

Surface HRC

Core HRC

Microstucture

ZDCr28

≥62

≥62

M+C

ZDCr26

≥62

≥62

M+C

ZDCr23

≥62

≥62

M+C

ZDCr20

≥62

≥62

M+C

ZDCr17

≥62

≥62

M+C

ZDCr15

≥62

≥62

M+C

ZDCr12

≥62

≥62

M+C

ZDCr8

50-55

50-55

P+C/M+C

ZDCr5

50-55

50-55

P+C/M+C

ZDCr2

≥48

≥47

P+C

ZDCADI

55-60

55-60

B+Fe

C-Carbide       M-Martensite      A-Ferrite      B-Bainit       Fe-Ferrite

SPECIFICATION

Specification (mm）

Weight of Each Ball (Kg)

Pcs/ton

φ8×10

0.0039

255056

φ10×12

0.0074

136030

φ12×14

0.0120

80970

φ14×16

0.0190

52052

φ16×18

0.0280

35424

φ18×20

0.0400

25191

φ20×25

0.0610

16324

φ25×30

0.1150

8706

φ30×35

0.1930

5182

φ35×40

0.3000

3331

φ40×45

0.4400

2267

φ45×55

0.5711

1751

φ55×60

0.8611

1161

Our advantage
The medium chromium grinding and forging materials have reached an ideal balance point between wear resistance and economy. Compared with high chromium forging, medium chromium grinding forging not only ensures sufficient wear resistance, but also reduces the manufacturing cost , enables customers to obtain quality products at the same time, can also enjoy a more affordable price. This material is suitable for medium load and wear ball mill applications, is a cost-effective choice. chromium grinding forging has good wear resistance, corrosion resistance and toughness, is suitable for some occasions that do not require high material properties. Compared with high chromium forging, the manufacturing cost of chromium grinding forging is relatively low, processing difficulty is less, can meet the manufacturing needs of some common mechanical parts and structures. Although its performance is relatively mediocre, is not as good as high chromium forging in some special situations, in many applications medium chromium grinding provides an economical and effective solution.
